Nominal dimensions: 60” W x 33” D x 56” H (can be customized)

X-Y positioner scan travel: 18.5” x 8.3”

Imaging field of view: 50 mm

Magnification: 4 to 20 times, continuous zoom

Voltage requirement: 110 or 220 VAC, 50-60 Hz

Current Requirement: 15 amps

X-ray tube anode voltage: 20 kV to 70 kV, variable

Tube current: 100 microamps

Image resolution: 14 line-pairs per millimeter. Can resolve a 0.001 inch wire.

Image processor: GTI-1000 available with standard CPU

Glenbrook – Mailscope

Nominal dimensions: 60” W x 33” D x 56” H (can be customized)

X-Y positioner scan travel: 18.5” x 8.3”

Imaging field of view: 50 mm

Magnification: 4 to 20 times, continuous zoom

Voltage requirement: 110 or 220 VAC, 50-60 Hz

Current Requirement: 15 amps

X-ray tube anode voltage: 20 kV to 70 kV, variable

Tube current: 100 microamps

Image resolution: 14 line-pairs per millimeter. Can resolve a 0.001 inch wire.

Image processor: GTI-1000 available with standard CPU
